Mains Pressure Vitreous Enamel

Mains Pressure Vitreous Enamel

Vitreous Enamel lined hot water cylinders provide the best corrosion resistance to a wide range of water conditions including varying pH levels, high chlorides, hard water and MIC (Microbiological Induced Corrosion) as found in parts of the country and areas with untreated bore water. This range continues to be popular in the hot water storage market and superior durability in all water conditions.

Features
  • All Vitreous Enamel (VE) water heaters are fitted with a sacrificial zinc/magnesium anode to provide additional corrosion protection to the cylinder in adverse water conditions
  • Twin and dual element models available
  • Also suitable for unequal pressure and low pressure uses
  • 10 year cylinder warranty*
Sustainability Facts
  • All VE water heaters meet or exceed the NZ MEPS (Minimum Energy Performance Standards).
  • The water heaters have recyclable galvanised steel jackets (outer casing) and steel (inner) tanks, as well as recyclable valves. Recyclable cardboard packaging is used only on the top rim of the water heater, meaning there is no unnecessary waste.
  • High quality Solstice ZD insulation allows the optimum water temperature to be maintained longer, which results in reduced energy usage and lower costs. Solstice ZD also has very low GWP (Global Warming Potential) and zero ozone-depleting properties.

* The specified cylinder residential warranty period and the commercial warranty period are for VE products manufactured after 1 June 2018.

Download brochure
Mains Pressure Vitreous Enamel
Model Approx. Storage Capacity (Litres) Dimensions (HxW) Installation Location Element Rating (kW)
MPVE 31202519V 25 398 x 400mm Indoor 2.0
MPVE 31204513 43 525 x 490mm Indoor 2.0
MPVE 31204515 43 525 x 490mm Indoor 3.0
MPVE 31209013 88 925 x 490mm Indoor 2.0
MPVE 31209015 88 925 x 490mm Indoor 3.0
MPVE 31213513 133 1325 x 490mm Indoor 2.0
MPVE 31213515 133 1325 x 490mm Indoor 3.0
MPVE 32213513 135 935 x 580mm Indoor 2.0
MPVE 32213515 135 935 x 580mm Indoor 3.0
MPVE 31218013 177 1710 x 490mm Indoor 2.0
MPVE 31218015 177 1710 x 490mm Indoor 3.0
MPVE 31218025 177 1710 x 490mm Indoor 2 x 3.0 non-simultaneous
MPVE 32218013 177 1165 x 580mm Indoor 2.0
MPVE 32218015 177 1165 x 580mm Indoor 3.0
MPVE 31225015 247 1555 x 580mm Indoor 3.0
MPVE 31225025 247 1555 x 580mm Indoor 2 x 3.0 non-simultaneous
MPVE 31230015 294 1815 x 580mm Indoor 3.0
MPVE 31230033 294 1815 x 580mm Indoor 2 x 3.0 simultaneous
MPVE 31230055 294 1815 x 580mm Indoor 2 x 5.0 simultaneous
